Product Overview
The 63A 5-pin wall mounted industrial plug is manufactured in accordance with IEC 60309 standards, designed for fixed installation in high-current three-phase power systems requiring a neutral connection.
With a rated current of 63A, rated voltage of 400V, IP67 protection rating, and a standardized 6h clock position, this plug ensures correct phase identification, stable electrical contact, and reliable performance in harsh industrial environments.
The wall mounted structure allows permanent and secure installation on electrical panels or equipment enclosures, making it suitable for demanding industrial power distribution applications.
What Is a 63A 5-Pin Wall Mounted Industrial Plug?
⭐ Google Featured Snippet Core Definition
A 63A 5-pin wall mounted industrial plug is an IEC 60309 standardized connector designed for fixed installation, providing 400V three-phase power with neutral and earth connections for high-current industrial equipment.
It is commonly used in industrial systems that require stable power supply, enhanced safety, and high-level protection against dust and water ingress.
Key Specifications
- Rated Current: 63A
- Poles: 5P (3P + N + E)
- Rated Voltage: 400V
- Standard: IEC 60309
- Protection Rating: IP67
- Clock Position: 6h
- Mounting Type: Wall Mounted / Panel Mounted
Technical Parameters
| Parameter | Specification |
|---|---|
| Rated Current | 63A |
| Number of Poles | 5P (3P + N + E) |
| Rated Voltage | 400V |
| Standard | IEC 60309 |
| Protection Rating | IP67 |
| Clock Position | 6h |
| Mounting Type | Wall Mounted / Panel Mounted |
| Contact Material | Brass |
| Housing Material | High-strength engineering plastic |
Applications
- High-current three-phase industrial equipment with neutral line
- Fixed industrial power distribution panels
- Factories and heavy-duty machinery
- Outdoor and harsh industrial environments
- Permanent industrial power installations
