Device Inlet 63A / 3P-1107 IP67 230V is designed in accordance with IEC 60309 standards and features blue voltage coding for 230V, suitable for single-phase power systems (L + N + Earth).
This panel mount device inlet is intended for fixed installation on industrial equipment, electrical enclosures, and power distribution systems, serving as a high-current single-phase power input interface. When used with compatible industrial connectors, it ensures safe and correct power connections.
The housing is made of high-strength flame-retardant engineering plastic, providing excellent resistance to impact, heat, corrosion, and aging under continuous high-current operation.
With an IP67 protection rating, the device inlet offers full dust protection and resistance to temporary water immersion, making it ideal for outdoor and harsh industrial environments.
⭐ Key Features
Rated Current: 63A
Rated Voltage: 230V (IEC Blue Coding)
Poles: 3P (L + N + Earth)
Product Type: Device Inlet / Panel Mount Plug
Mounting Type: Equipment / Panel Mount
Protection Rating: IP67
IEC 60309 compliant
High-conductivity copper alloy pins
Dustproof and waterproof industrial design
⭐ Typical Applications
High-current single-phase industrial equipment
Industrial heating and power systems
Outdoor and wet-environment installations
Industrial machinery and automation
Control panels and distribution systems
Equipment maintenance and testing connections
