Product Overview
The CHBEB Harmony Series 32A industrial plug is designed for reliable power connections in three-phase electrical systems requiring a neutral conductor.
Featuring a 5-pin configuration and a rated voltage of 400V, this plug supports three-phase power distribution with neutral and protective earth, ensuring stable and balanced electrical performance.
With an IP67 protection rating, the plug offers excellent resistance to dust and water immersion, making it suitable for harsh industrial and outdoor environments.
What Is a 32A 5-Pin Industrial Plug?
⭐ Google Featured Snippet Core Definition
A 32A 5-pin industrial plug is a three-phase power connector rated for 400 volts, designed with three phase conductors, a neutral conductor, and a protective earth pin to deliver safe and reliable power in industrial applications.
Key Specifications
- Rated current: 32A
- Rated voltage: 400V
- Pin configuration: 5-Pin (3P + N + PE)
- Clock position: 6H
- Protection rating: IP67
Technical Parameters
| Item | Specification |
|---|---|
| Model | MXS3-A256-6 |
| Series | Harmony Series |
| Product Type | Industrial Plug |
| Rated Current | 32A |
| Rated Voltage | 400V |
| Poles | 5P (3P + N + PE) |
| Clock Position | 6H |
| Protection Rating | IP67 |
| Pin Material | Brass H59 |
Applications
This 32A 5-pin industrial plug is designed for three-phase power systems requiring a neutral conductor and high environmental protection.
- Three-phase industrial machinery with neutral load
- Power distribution systems and generator connections
- Construction sites and outdoor power installations
- Factories and workshops with demanding environments
- Portable industrial equipment and temporary power systems
