Product Overview
The CHBEB MX Series 32A 5-Pin Flanged Industrial Socket is designed in accordance with IEC 60309 standards and developed for secure panel-mounted industrial power distribution systems.
With a rated current of 32A, rated voltage of 400V, 5-pin (3P+N+E) configuration, and IP44 protection rating, this socket provides stable power transmission with protection against solid objects and water splashes. The red color coding and 6h clock position ensure correct voltage identification and safe connection.
The flanged mounting design allows reliable installation on panels, enclosures, and industrial equipment, making it suitable for fixed electrical installations.
What Is a 32A 5-Pin Flanged Industrial Socket?
⭐ Google Featured Snippet Core Definition
A 32A 5-pin flanged industrial socket is an IEC 60309 standardized three-phase power outlet with neutral and earth, designed for panel mounting and used to safely distribute 400V industrial power.
It ensures stable phase distribution, neutral continuity, reliable grounding, and long-term operational safety in industrial environments.
Key Specifications
- Rated current: 32A
- Rated voltage: 400V
- Pin configuration: 5-Pin (3P+N+E)
- Protection rating: IP44
- Clock position: 6h
- Color code: Red (400V)
- Mounting type: Flanged / Panel Mounted
- Series: MX
- Standard: IEC 60309
Technical Parameters
| Item | Specification |
|---|---|
| Model | MXS3-B254-6 |
| Product Type | Flanged Industrial Socket |
| Rated Current | 32A |
| Rated Voltage | 400V |
| Poles | 5P (3P+N+E) |
| Protection Rating | IP44 |
| Clock Position | 6h |
| Color | Red |
| Pin Material | H59 Brass |
| Housing Material | Industrial-grade insulating plastic |
| Standard | IEC 60309 |
Applications
The CHBEB MX Series 32A IP44 5-pin flanged industrial socket is widely used in:
- Three-phase equipment requiring neutral connection
- Industrial machines with mixed loads
- Electrical control panels
- Factories and workshops
- Fixed industrial power distribution systems
FAQ
Why choose a 5-pin socket instead of a 4-pin?
A 5-pin socket includes a neutral conductor, making it suitable for equipment that requires both three-phase and single-phase power.
Is IP44 suitable for industrial applications?
Yes. IP44 protection is suitable for indoor and semi-outdoor industrial environments where water splashes may occur.
Is this socket compatible with IEC 60309 plugs?
Yes. This socket fully complies with IEC 60309 standards and is compatible with corresponding 32A 5-pin IEC industrial plugs.
Why Choose CHBEB MX Series?
- Complete MX flanged socket range from 16A to 125A
- Available in IP44 and IP67 protection levels
- Strict IEC 60309 compliance
- Durable structure for fixed industrial installations
- OEM and customization services available
