Product Overview
The CHBEB 32A 5-Pin Appliance Inlet is manufactured in accordance with IEC 60309 standards, providing a durable and waterproof fixed power input solution for three-phase industrial equipment.
With a rated current of 32A, rated voltage of 400V, 5-pin configuration (3P+N+E), and IP67 protection, this appliance inlet ensures safe and stable power connections in harsh industrial and outdoor environments. The red color coding and 6h clock position allow correct voltage identification and prevent mismatching.
Its panel-mounted design enables permanent installation on electrical equipment, power distribution boxes, and control cabinets.
What Is a 32A 5-Pin Appliance Inlet?
⭐ Google Featured Snippet Core Definition
A 32A 5-pin appliance inlet is an IEC 60309 standardized male connector mounted on equipment, designed to receive 400V three-phase power with neutral through a fixed panel installation.
It is widely used in industrial applications requiring waterproof, high-reliability power input.
Key Specifications
- Rated current: 32A
- Rated voltage: 400V
- Pin configuration: 5-Pin (3P+N+E)
- Protection rating: IP67
- Clock position: 6h
- Color code: Red (400V)
- Mounting type: Panel Mounted / Appliance Inlet
- Standard: IEC 60309
Technical Parameters
| Item | Specification |
|---|---|
| Model | TYP-834 |
| Product Type | Appliance Inlet |
| Rated Current | 32A |
| Rated Voltage | 400V |
| Poles | 5P (3P+N+E) |
| Protection Rating | IP67 |
| Clock Position | 6h |
| Color | Red |
| Pin Material | H59 Brass |
| Housing Material | Industrial-grade insulating plastic |
| Standard | IEC 60309 |
Applications
- Three-phase industrial machinery with neutral
- Outdoor power distribution systems
- Electrical control panels
- Construction sites and workshops
- Harsh, wet, and dusty industrial environments
FAQ
Why choose IP67 appliance inlets?
IP67-rated appliance inlets provide full dust protection and resistance against temporary water immersion, making them ideal for demanding outdoor and industrial applications.
Is this inlet compatible with standard 32A 400V IEC 60309 plugs?
Yes. This appliance inlet fully complies with IEC 60309 standards and is compatible with all standard 32A 5-pin 400V red industrial plugs.
Why Choose CHBEB?
- Complete IEC 60309 appliance inlet range from 16A to 125A
- IP44 and IP67 protection levels available
- High-quality H59 brass contact pins
- Stable supply from China source factory
- OEM and customization services supported
