The Harmony Series 32A/3P-MXS3-B236-6 IP67 230V Panel Mount Socket is designed according to IEC 60309 blue voltage coding, suitable for single-phase industrial power systems (2P + Earth), delivering a safe and highly protected 230V power connection.
This panel-mounted socket is ideal for fixed installation on equipment enclosures, control panels, and distribution boards, especially in outdoor or harsh industrial environments where water and dust protection is required.
The housing is manufactured from high-strength flame-retardant PA66, offering excellent resistance to impact, heat, corrosion, and aging for long-term industrial use.
With an IP67 protection rating, the socket provides full dust protection and resistance to temporary water immersion when mated.
A screw-type sealing cover ensures reliable protection when not in use, preventing water, dust, and contaminants from entering the socket.
Key Features
Rated Current: 32A
Rated Voltage: 230V (IEC Blue Coding)
Poles: 3P (2P + Earth)
Mounting Type: Panel Mount Socket
Protection Rating: IP67
Flame-retardant PA66 housing
High-conductivity copper alloy contacts
Screw-type sealing cover for enhanced protection
Compatible with Harmony Series 32A single-phase industrial plugs
Typical Applications
Outdoor industrial equipment
Automation systems and production lines
Construction sites and engineering machinery
Ports, docks, and humid environments
Food processing and wash-down areas
Industrial maintenance and service connections
