Panel Mount Inlet 32A/3P-817 IP44 230V is designed for single-phase 230V power systems (L + N + PE) and follows IEC 60309 blue voltage coding, ensuring safe and correct power connections in industrial and commercial environments.
This model features a panel-mounted inlet design, allowing secure installation on equipment enclosures, control panels, and distribution boards.
The housing is manufactured from high-strength flame-retardant PA66, offering excellent resistance to impact, heat, corrosion, and aging.
With an IP44 protection rating, the inlet is protected against solid objects larger than 1 mm and water splashes, making it suitable for indoor and semi-outdoor applications where reliable performance and cost efficiency are required.
⭐ Key Features
Rated Current: 32A
Rated Voltage: 230V (IEC Blue Coding)
Poles: 3P (Live + Neutral + Earth)
Mounting Type: Panel Mount Inlet
Protection Rating: IP44
Durable flame-retardant PA66 housing
Nickel-plated copper contacts for stable conductivity
IEC 60309 compliant for system compatibility
Designed for frequent industrial use
⭐ Typical Applications
Single-phase 230V industrial equipment
Control panels and distribution boards
Workshop machinery and production lines
HVAC and ventilation systems
Warehouses and logistics facilities
Commercial and industrial power distribution
