Product Overview
The CHBEB 16A 5-Pin Appliance Inlet is manufactured in compliance with IEC 60309 standards, providing a safe and reliable panel-mounted power input solution for three-phase industrial equipment.
With a rated current of 16A, rated voltage of 400V, 5-pin (3P+N+E) configuration, and IP44 protection, this appliance inlet ensures stable power transmission and safe operation. The red color coding and 6h clock position allow correct voltage identification and prevent incorrect connections.
Its compact panel-mounted design makes it ideal for fixed installation on industrial machines, electrical cabinets, and power distribution equipment.
What Is a 16A 5-Pin Appliance Inlet?
⭐ Google Featured Snippet Core Definition
A 16A 5-pin appliance inlet is an IEC 60309 standardized male connector mounted on electrical equipment, designed to receive 400V three-phase power with neutral safely and reliably.
It is commonly used as a power input interface for industrial machinery, control panels, and fixed electrical installations.
Key Specifications
- Rated current: 16A
- Rated voltage: 400V
- Pin configuration: 5-Pin (3P+N+E)
- Protection rating: IP44
- Clock position: 6h
- Color code: Red (400V)
- Mounting type: Panel Mounted / Appliance Inlet
- Standard: IEC 60309
Technical Parameters
| Item | Specification |
|---|---|
| Model | TYP-815 |
| Product Type | Appliance Inlet |
| Rated Current | 16A |
| Rated Voltage | 400V |
| Poles | 5P (3P+N+E) |
| Protection Rating | IP44 |
| Clock Position | 6h |
| Color | Red |
| Pin Material | H59 Brass |
| Housing Material | Industrial-grade insulating plastic |
| Standard | IEC 60309 |
Applications
The CHBEB 16A IP44 5-pin appliance inlet is widely used in:
- Three-phase industrial machinery with neutral
- Electrical control cabinets
- Automation and production equipment
- Industrial power distribution systems
- Indoor and semi-protected industrial environments
FAQ
What is the difference between a 4-pin and 5-pin appliance inlet?
A 5-pin appliance inlet includes a neutral conductor (3P+N+E), making it suitable for equipment requiring both three-phase and single-phase loads.
Is IP44 protection sufficient for industrial use?
Yes. IP44 protects against solid objects and water splashes, making it suitable for indoor and light industrial environments.
Is this inlet compatible with IEC 60309 industrial plugs?
Yes. This appliance inlet is fully compatible with corresponding IEC 60309 16A 5-pin industrial plugs.
Why Choose CHBEB?
- Complete IEC 60309 appliance inlet product range
- Current ratings from 16A to 125A
- IP44 and IP67 protection options
- High-quality H59 brass contacts
- OEM and customization services available
