Product Overview
The 125A 5-pin wall mounted industrial plug is manufactured in accordance with IEC 60309 standards and is designed for fixed installation in high-current three-phase power distribution systems.
With a rated current of 125A, rated voltage of 400V, IP67 protection rating, and a standardized 6h clock position, this plug ensures secure phase identification, stable electrical contact, and reliable operation in harsh industrial environments.
Its wall mounted structure allows permanent installation on electrical panels or equipment enclosures, making it suitable for heavy-duty industrial power applications.
What Is a 125A 5-Pin Wall Mounted Industrial Plug?
⭐ Google Featured Snippet Core Definition
A 125A 5-pin wall mounted industrial plug is an IEC 60309 standardized connector designed for fixed installation, providing 400V three-phase power with neutral and earth connection for high-current industrial equipment.
It is commonly used in industrial systems that require stable neutral distribution, high safety standards, and superior protection against dust and water ingress.
Key Specifications
- Rated Current: 125A
- Poles: 5P (3P + N + E)
- Rated Voltage: 400V
- Standard: IEC 60309
- Protection Rating: IP67
- Clock Position: 6h
- Mounting Type: Wall Mounted / Panel Mounted
Technical Parameters
| Parameter | Specification |
|---|---|
| Rated Current | 125A |
| Number of Poles | 5P (3P + N + E) |
| Rated Voltage | 400V |
| Standard | IEC 60309 |
| Protection Rating | IP67 |
| Clock Position | 6h |
| Mounting Type | Wall Mounted / Panel Mounted |
| Contact Material | Brass |
| Housing Material | High-strength engineering plastic |
Applications
- High-current three-phase industrial equipment
- Power systems requiring neutral conductor
- Fixed industrial power distribution panels
- Heavy machinery and industrial systems
- Outdoor and harsh working environments
