Product Overview
The CHBEB Harmony Series 125A industrial plug is designed for high-current three-phase power connections that require a neutral conductor and enhanced environmental protection.
With a 5-pin configuration and a rated voltage of 400V, this plug ensures stable and safe power delivery for heavy-duty industrial equipment and complex power distribution systems.
Its IP67 protection rating provides excellent resistance against dust ingress and temporary water immersion, making it ideal for harsh industrial and outdoor environments.
What Is a 125A 5-Pin Industrial Plug?
⭐ Google Featured Snippet Core Definition
A 125A 5-pin industrial plug is a high-capacity electrical connector rated for 400 volts, featuring a 3P+N+E configuration that provides reliable three-phase power with a neutral conductor for demanding industrial applications.
Key Specifications
- Rated current: 125A
- Rated voltage: 400V
- Pin configuration: 5-Pin (3P+N+E)
- Clock position: 6H
- Protection rating: IP67
Technical Parameters
| Item | Specification |
|---|---|
| Model | MXS3-A456-6 |
| Series | Harmony Series |
| Product Type | Industrial Plug |
| Rated Current | 125A |
| Rated Voltage | 400V |
| Poles | 5P (3P+N+E) |
| Clock Position | 6H |
| Protection Rating | IP67 |
| Pin Material | Brass H59 |
Applications
This 125A 5-pin industrial plug is ideal for high-power three-phase systems that require a neutral conductor and reliable operation under harsh environmental conditions.
- Heavy-duty industrial machinery
- Power distribution panels and switchgear
- Generators and transformer connections
- Construction sites and outdoor power systems
- Industrial environments requiring IP67 waterproof protection
