Harmony Series Panel Mount Socket 125A/4P-MXS3-B446-6 IP67 400V is designed for three-phase power systems (3P + Earth) and complies with IEC 60309 red voltage coding, ensuring safe and correct 400V connections for high-current industrial applications.
This panel-mounted socket is intended for fixed installation on heavy-duty equipment enclosures, control cabinets, and industrial power distribution systems, providing a reliable 125A three-phase power interface for demanding load conditions.
The housing is manufactured from high-strength flame-retardant PA66, offering excellent resistance to impact, heat, corrosion, and aging, even under continuous high-current operation.
With an IP67 protection rating, the socket is fully protected against dust ingress and temporary water immersion, making it ideal for outdoor, wet, and harsh industrial environments.
A screw-type sealed protective cover ensures reliable contact protection when not in use, enhancing operational safety and extending service life.
⭐ Key Features
Rated Current: 125A
Rated Voltage: 400V (IEC Red Coding)
Poles: 4P (3P + Earth)
Mounting Type: Panel Mount Socket
Protection Rating: IP67
Flame-retardant PA66 housing for heavy-duty use
High-conductivity copper alloy contacts
Screw-type sealed protective cover
Compatible with Harmony Series 125A three-phase industrial plugs
⭐ Typical Applications
High-current three-phase industrial equipment
Heavy-duty machinery and power systems
Industrial control cabinets and distribution boards
Outdoor and harsh industrial environments
Construction sites and temporary high-load power supply
Maintenance, testing, and emergency power connections
